Description Quickly and reliably detects all types of RF surveillance devices in the range up to 6 GHz, including analog, digital, working continuously and periodically, transmitting audio or video, with or without encryption Finds and identifies covert surveillance devices which use the digital standards GSM, 3G, 4G / LTE, 5G, Bluetooth, Wi-Fi, DECT and others in the range up to 6 GHz Analyzes Wi-Fi 2.4 GHz, Wi-Fi 5 GHz, Bluetooth, “Bluetooth LE” and “Bluetooth LE Advertising” channels The background masking feature allows you to reject friendly signals such as television, radio, mobile base stations, etc., and focus on finding local signals that pose a danger Can be quickly adjusted to the local frequency allocation in the country of use (mobile and wireless bands) High-speed spectrum updating and wide real-time bandwidth (RTBW) provide the ability to register short-burst signals Search modes include: “All Signals”, “Mobile/GPS trackers”, “Wireless/ISM” and “Custom”, as well as two additional modes for the inspection of suspicious bands or signals Two antenna inputs and built-in antenna switch provide maximum sensitivity over the entire frequency range Unlimited number of logs, each can contain an unlimited history of events Unlimited number of logs, each can contain an unlimited history of events The audio alarm warns the user about the presence of danger with a sound of variable intensity The attenuator simplifies location of powerful transmitters The “Hold maximum danger” feature automatically displays the most dangerous band or signal Demodulation of audio in AM/FM mode Works with, and is powered by, a laptop or tablet (not included) Has convenient magnetic system for attaching the laptop / tablet to the main unit Frequency range 57-6000 MHz Sweeping speed 8 GHz per second ADC resolution 12 bit Sensitivity -85 dB Dynamic range 80 dB (with attenuator) Displayed signal level -90…-10 dB Real-time bandwidth (RTBW) 27 MHz Format Handheld unit Platform SDR by Analog Device Antenna inputs INPUT 1 – SMA, 57-2000 MHz INPUT 2 – SMA, 2000-6000 MHz Searching modes and time of update • All signals (~0.8 s) • Mobile/GPS trackers (~0.2 s) • Wireless/ISM (~0.3 s) • Inspect band/signal (~0.1-0.2 s) Visual elements (panels) • Level • Spectrum Waterfall • Alarms Demodulation AM and FM with bandwidth 5, 15, 30, 100 and 200 kHz (in the range 70-6000 MHz) Requirements for laptop / tablet Intel Core і3 / AMD Ryzen 3 or better (recommended Intel Core i5 / AMD Ryzen 5) 2 USB ports, one should be of SuperSpeed type (USB 3.0/3.1/3.2 or USB Type C) RAM 8 Gb or more SSD 128 Gb or more Windows 8,10,11. Screen size 12-14” Powered by USB-port of laptop / tablet Battery resource 1-1.5 hour Duration of work from AC Unlimited Displayed spectrum span 2 – 6000 MHz Range of working temperature -5°C… 45°C / 23°F … 113°F Signal Detection Digital Signals 3G 4G 5G GPS CDMA GSM Bluetooth Wi-Fi LTE Analog Signals Detection Range Up to 6 Ghz
