DescriptionThe Vostok WTF Electric Scooter is designed to excel in any environment—whether you’re cruising through city streets, navigating challenging crossroads, or speeding through highway traffic. This foldable scooter is compact enough to fit inside your car trunk, making it a perfect companion for your urban adventures.We’ve integrated advanced technology and cutting-edge design to provide an unforgettable driving experience:High-powered 27 kW motor-wheel for exceptional performance.Built-in liquid cooling system in both the motor-wheel and frame for optimal efficiency.Structural elements made from titanium and airplane-grade aluminum for superior durability.An extra-durable waterproof frame ensures longevity in all weather conditions.Equipped with long-travel, pneumatic high-performance suspension for a smooth ride.Unique design of steering and controls for enhanced maneuverability.Features a state-of-the-art customized controller for precision and reliability.The Vostok WTF Electric Scooter is the perfect combination of power, durability, and sleek design—ready to take on any challenge, wherever your journey leads.1. General InformationAttributeDetailsMaximum Speed110 km/hAcceleration (0-100 km/h)6 secondsWeight94 kgMaximum Payload200 kgRange on one charge (at 100 km/h)60 kmRange on one charge (at 60 km/h)110 kmRange on one charge (at 30 km/h)160 kmBattery Charging Time (0-100%)2 hours2. EngineAttributeDetailsEngine TypeMotor-wheel with integrated liquid coolingHall SensorsTwo setsTiresTubeless, rain tire for go-kartMaximum Power27 kWMagnet Operating TemperatureUp to 150°CIngress ProtectionIP673. AccumulatorAttributeDetailsVoltage66-92.4 VCapacity6.5 kWhMaximum Discharge Current400 ALong-term Discharge Current250 AMaximum Charge Current80 A4. SuspensionAttributeDetailsRear SuspensionMulti-linkFront SuspensionLever typeSuspension Travel160 mm5. FrameAttributeDetailsCooling SystemIntegrated liquid coolingWiringConcealedMaterial (Basic Elements)Machined, aircraft-grade aluminum (D16T)Material (Power Elements)Titanium (OT4)BearingsSKFSteering Cup BearingsTapered, roller, angular contact, 25 tons max loadMaximum Static Load (Elastic Deformation)650 kgIngress ProtectionIP656. Brake SystemAttributeDetailsFront BrakeHydraulicRear BrakeHydraulic ventilated regenerativeRegenerative BrakeAdjustable brake force, trigger-controlled7. LED OpticsTypeLED headlight with lensBrightness4600 lm (mid) 4600 lm (far)Number of Lights2Power (per Lamp)36 W8. ControlTriggersTwo, multi-functional, shockproofSensor PrincipleHall sensorMechanicsBall bearingMaterialsMilled, aircraft-grade aluminumMulti-function ButtonsFor main and additional controller functionsWater Protection ClassIP54 (upgrade in progress)9. Battery ChargerTypeServer-based power supply chargerCharging Time0-100% in 2 hours10. ElectronicsAttributeDetailsController (Max Battery Current)350 AController (Max Phase Current)500 ADisplay TypeMulti-function, shockproof, waterproofScreen ProtectionTempered Gorilla GlassControl KeysWaterproof, mechanicalDisplay Ingress ProtectionIP66 Main Controls and Operating RulesBefore Using the Scooter for the First Time, It Is Necessary to: 1. Fully charge the battery. 2. Check the tire pressure (1.8 atmospheres in both the front and rear wheels). 3. Adjust the shock absorbers according to your weight and intended riding style.Transition from Transport Position to Working Position: 1. Loosen the screws on the middle and upper clamps (see Figure 1). 2. Raise the steering mast to the limiter. 3. Tighten the screws on the middle and upper clamps (see Figure 1). 4. Spread the right and left halves of the handlebars. 5. Tighten the connecting nut (see Figure 3).Turning On/Off: 1. Press and hold the BMS power button on the back of the deck (see Figure 2) until you hear a beep. 2. Move the onboard computer power button towards the screen. 3. The scooter is ready for use.Charging: 1. Turn on the scooter. 2. Disconnect the charging station from the scooter (see Figure 1). *Important:* Ensure that the body of the charging device does not contact the scooter’s body. 3. Insert the connector into the wiring connection port (see Figure 4). – Be sure to open the air ducts to prevent damage to the charging station (see Figure 4). 4. Connect the charging station to the 220V power supply, then insert the connector into the charging port (see Figure 2). 5. The onboard computer’s display will show the charging screen. 6. After the charging process is complete, first remove the connector from the charging port (see Figure 2), then disconnect the charging station from the 220V power supply.Figures Figure 1. General View: 1. Charging station 2. Middle clamp 3. Upper clamp 4. Back wall of the deckFigure 2. Back Wall of the Deck: 1. Charging port 2. BMS power buttonFigure 3. Handlebar: 1. Control buttons for the onboard computer (detailed instructions on the onboard computer) 2. Reverse 3. Power on the onboard computer 4. Throttle lever 5. Cooling system power on 6. ”ECO” mode (power and maximum speed limitation) 7. Low beam 8. Electronic brake lever 9. High beam 10. Connecting nutFigure 4. Charging Station: 1. Wiring connection port 2. Air duct flapsPrecautions: • Do not leave the scooter unattended while charging. • Do not press the throttle lever when the charging connector is plugged in (see Figure 2) if the charging station is unplugged from the 220V power supply.
