Description The Goldring E Series cartridges feature a dual magnet arrangement. Magnetic Duplex Technology uses two low mass magnets which interact only with their partnering pickup coil, angled at 45 ̊ to match the cutting head arrangement. This enables the cartridges to more accurately trace the record groove because they precisely emulate the geometry of the cutting head, “making for better stereo separation and a more accurate, involving and musical soundstage” Specifications Colour Red Cantilever Carbon Stylus profile Spherical Stylus radius 0.6 mil Transducer Characteristics Frequency range 20 Hz – 20 kHz Channel balance 1.5 dB at 1 kHz Channel separation >20 dB at 1 kHz Sensitivity 3.5 mV (1 kHz @ 5 cm/sec) Static compliance 20 mm/N Vertical tracking angle 208 Electrical Characteristics Load resistance 47 kOhm Load capacitance 100 – 200 pF Internal inductance 400 mH Internal resistance 410 Ohm Mechanical Characteristics Cartridge mass 6.9 g Fixing centres 12.7 mm (0.5 in) Playing weight 1.5 g – 2.5 g (2.0 g recommended)
